Model
|
IN
|
L16-50K
|
|
OUT
|
L16-50K
|
|
|
Operating frequency
|
3 MHz ～ 30 MHz
|
|
|
Characteristic impedance of port
|
50 Ω
|
|
|
Applicable power
|
60 W
|
|
|
Insertion loss
|
≤ 0.2 dB
|
|
|
VSWR
|
≤ 1.2
|
|
|
Limit voltage 10/700 μs
|
≤ 300 V
|
|
|
Max. discharge current Imax 8/20 μs
|
10 kA
|
|
