Model
|
ZGZH-64
|
|||
|
Power Supply
|
||||
|
Nominal operating voltage UO
|
220 V AC
|
|||
|
Max. continuous operating voltage Uc
|
385 V AC
|
|||
|
Operating frequency
|
50/60 Hz
|
|||
|
Nominal discharge current In (8/20 μs)
|
L-PE, N-PE
|
10 kA
|
||
|
Max. discharge current Imax (8/20 μs)
|
L-PE, N-PE
|
20 kA
|
||
|
Limiting voltage (8/20 us, 10 KA)
|
≤ 1.2 kV
|
|||
|
Rated load current IL
|
4 A
|
|||
|
Protection mode
|
L-PE; N-PE
|
|||
|
Video Signal
|
||||
|
Max. continuous operating voltage Uc
|
5 V
|
|||
|
Type of connection
|
RJ45
|
|||
|
Transmission rate
|
100 Mbit/s
|
|||
|
Insertion loss
|
≤ 1 dB
|
|||
|
Impulse limiting voltage I (10/700 μs)
|
≤ 30 V
|
|||
|
Impulse limiting voltage II
(1.2/50 us, 8/20 us) |
L-L (600 V; 300 A)
|
≤ 70 V
|
||
|
Impulse limiting voltage II
(1.2/50 μs, 8/20 μs) |
L-PE (6 KV; 3 KA)
|
≤ 150 V
|
||
|
Impulse durability
|
L-L
|
1.2/50 us 600 V, 8/20 us 300 A
|
||
|
L-PE
|
1.2/50 us 6 KV, 8/20 us 3 KA
|
|||
|
SE-PE
|
1.2/50 us 10 KV, 8/20 us 5 KA
|
|||
|
Protected object
|
1, 2; 3, 6
|
|||
